High Power Digital Amplifiers Board TDA3116D2 Two Channel Audio Amplifier Board 12-24V 100Wx2
vary vary nice product and voice
Thank You Very Much! Parcel arrived quickly!
Прикхало quickly from Russia service sdek, but don't courier and self. All work, complete plastic pad on the volume knob and plastic fasteners, board. Match the description.
HiThere was a problem with the package.Damaged, addressing was wrong.They took him back to Budapest.By late, but here it is.Everything is alright.Thanks.Have a nice day.
Very fast delivery, if stock RF 4 days since the.
Store Name: Yimaglobal Store
Normal Price: US $12.99
Sale Price: US $10.78 (Discount: 17%)
Spesifications
Descriptions
Related Productions:
Feature
Packaging Including:
1 x PC Audio Amplifier Board
Product Questions
1. Amplifier board has current sound and noise during use
Most of our amplifier board use DC power supply. The board itself does not produce current sound and noise.
The main causes of current acoustic noise are:
A, The power supply filter used is not good; the current sound is caused by wrong input by the power or audio input.
B, The input signal quality is poor; the output of the device connected to the input is improper, and the noise is caused by the abnormal input of the audio source.
C, The input cable is of poor quality; the line is in poor connect; the wiring is damaged; the wiring is suspended
D, The input connection has other playback devices, and some devices share the power supply to cause noise.
2. No sound output, no sound in 1 channel?
A, The speaker is broken, or the speaker cable is not connect well.
B, The input cable is not in good connect; the wiring is damaged; the output of the device connected to the input is improper.
3. Volume broken and breaking sound when turn loud?
A, The power input is insufficient, confirm the wiring is correct first, and the supply current is sufficient,
B, The speaker itself has poor performance or damage, and the speaker power is too small or too large.
C, left and right channel speakers (+) (-) output are independent, can not be connected to each other
4. Speaker broken sound when subwoofer amplifier volume turn loud ?
A, The power input is insufficient, first confirm the wiring is correct, the supply current is enough
B, Whether the power of the speaker itself is too large or too small, or the bass performance of the speaker itself is poor; the structure of the speaker box; these abnormalities will cause breaks.
5.The volume power is not enough?
Power and power supply voltage, the amplitude of the sound source signal, the size of the speaker impedance are all related, any kind of deficiency will affect the power
6. Will the amplifier be burnt?
A, The positive and negative poles of the power supply are connected reversely; the power supply voltage is too high, exceeding the limit operating voltage of the board
B. If the board requires a DC power supply, it is not allowed to connect directly the AC transformer power supply (this can be rectified and converted to DC power before it can be used)
C. To confirm that the wiring is correct, then connect with the power supply. The wrong line connected or the short circuit both will cause damage to key parts.
Works good, sound pure quality on top. Good solder flux No. Very good item for small money
Powerful stuff and effective. Neighbors top very satisfied. AND ceiling, and pipe in company with вибродинамиком shakes well. Delivery very fast. Courier Service Special "thank you".Recommend!!!
It works)) приколотил through anchor to the ceiling (slab concrete) in apartment eating hear, as a neighbor's good! Барабанят on notable
Order received quickly, MO for 4 days. Board is packed in a cardboard box and a sealed vacuum bag. The Board looks good, clean soldering. Never connected to the power supply, so the work can not say, but assuming that everything will be fine.
Ordering from Russia, Krasnodar rode a week. Amp Is very small, but the task with a bang. Was bought for portable speaker-4 speakers by 25ВТ swings at full. After 10 minutes listening to the maximum volume chips warmed up to 45-50 degree (coated with thermal grease), first impressions are only positive, recommend to buy!
Package Details
- Unit Type:piece
- Package Weight:0.15kg (0.33lb.)
- Package Size:15cm x 15cm x 12cm (5.91in x 5.91in x 4.72in)
